ETM780S Concrete Installation Box
Concrete and precast wall box for pre-fabricated house factory installation; supplied without lid, with BULO and one 2×Ø20 mm inlet.
Product Overview
Flush mounting wall box for concrete and pre-fabricated house factory installation in the Universal Series. The catalog lists ETM780S without a lid, with BULO and one 2×Ø20 mm ETM793S inlet mounted on top.
Product Gallery
Engineering views from the current product record.
Key Features
- Universal Series; white box body
- Ø71 mm body; depth 60.5 mm; fixing centre 60 mm with M3 screws
- One 2×Ø20 mm ETM793S inlet mounted on top; without lid
- Locking springs and sealing plugs; modular system for ganged boxes
- Can be fastened to the mold with magnets; bottom ring for direct BULO use
- Suitable for concrete casting up to +90 °C
Downloads & Documents
Download Product SheetCatalogue Product SheetTechnical Specifications
| Specification | Value |
|---|---|
| Product Model | ETM780S |
| Product Type | Box |
| Product family | Concrete & Precast Boxes |
| Size / Depth | Ø71 mm body; depth 60.5 mm; drawing envelope 71 × 103 × 60 mm |
| Inlets | 1 × 2×Ø20 mm ETM793S inlet, mounted on top |
| Material | PP |
| IP Rating | IP30 |
| Conduit Entry | 2×Ø20 mm inlet; locking springs and sealing plugs |
| Fixing Method | Magnet fastening to the mold; bottom ring for direct BULO use; modular ganging; fixing centre 60 mm with M3 screws |
| Inner Ring Adjustment | Turnable ring; fixing centre 60 mm; M3 screws |
Application Context
Current product taxonomy lists this model under:
- Precast Concrete Plants
Market Fit Review
Selection depends on the project wall structure, conduit entry, mounting dimensions and local device system. Share your target market, existing model or drawing for a feasibility review.
- Target market
- Reference model or drawing
- Wall structure
- Device or cover frame requirement
- Certificate or declaration requirement
